Environment setup

Notes taken during the setup of the system

The System

BIOS/UEFI

To begin, once the hardware thrown in the case, we have to tune the BIOS/UEFI to enable some features in the advanced pannel :

• CPU Configuration >
  • CPU C States Support => Enabled
  • Enhanced Halt State (C1E) => Auto
  • Package C State Support => Enable
  • C6DRAM => Enable
• Chipset Configuration >
  • PCI Express Native Control => Enabled
  • PCH PCIE ASPM Support => Auto
  • Restore on AC/Power Loss => Power On

OS

For ease of use and support I will use Ubuntu Server 24.04.2 LTS even if alternative OS like nix are tempting.
To get the smallest footprint as possible, I installed the minimal configuration of Ubuntu server without any additional package except OpenSSH for remote access right after the installation.

Once the BIOS configured and the OS installed, let's take a look at the power consumption by installing powertop : sudo apt install powertop .Here we can see that the CPU can't go deeper that C2.

The main suspect is the ethernet controller, to set ASPM L1 for this controller :

echo 1 | sudo tee /sys/bus/pci/drivers/r8169/0000\:01\:00.0/link/l1_aspm

Then we can set the powersave mode for the PCI-e :

echo "powersave" | sudo tee /sys/module/pcie_aspm/parameters/policy
cat /sys/module/pcie_aspm/parameters/policy # to confirm

We can also use powertop --auto-tune to tweak other things.

And to persist all those commands, let's add them to the reboot cron :

# To persist those commands
(sudo crontab -l 2>/dev/null; echo "@reboot /usr/sbin/powertop --auto-tune") | sudo crontab -
(sudo crontab -l 2>/dev/null; echo "@reboot echo 1 | sudo tee /sys/bus/pci/drivers/r8169/0000\:01\:00.0/link/l1_aspm") | sudo crontab -
(sudo crontab -l 2>/dev/null; echo "@reboot echo "powersave" | sudo tee /sys/module/pcie_aspm/parameters/policy") | sudo crontab -

Power consumption

At this point the server sips just bellow 12 Watts at idle with HX750i, the N100DC-ITX motherboard, 32 Go of RAM and a 256 Go SATA SSD. Adding 2 12x12 fans add 1.5 Watts for a total bellow 13.5 W.

Networking

Let's change the SSH default port :

• Open ssh config sudo nano /etc/ssh/sshd_config
• Edit #Port 22 to something else
• Adding new port to firewall sudo ufw allow xxxx/tcp
• Apply change by restarting SSH sudo systemctl restart ssh.service
• Test the connection ssh <user>@<server_ip> -p xxxx
• Removing port 22 to firewall sudo ufw deny 22/tcp

Let's disable password connection for SSH

• Open ssh config sudo nano /etc/ssh/sshd_config
• Setting PasswordAuthentication no
• Setting PermitRootLogin prohibit-password
• Apply change by restarting SSH sudo systemctl restart ssh.service

Tips

• sudo ss -tulpn to list all the open ports
• Don't forget to fix the IP address of the homelab in the router

The tools

CLI utilities

sudo apt-get update
sudo apt install bash-completion
sudo apt install git
sudo apt install nano
sudo apt install cron
sudo apt install ufw
sudo apt install pipx && python3 -m pipx ensurepath && pipx install mkdocs && pipx inject mkdocs mkdocs-material

Docker

The first tool to install and Setup is Docker.

Docker installation

Following the official documentation :

Setup the apt repository :

# Add Docker's official GPG key:
sudo apt-get update
sudo apt-get install ca-certificates curl
sudo install -m 0755 -d /etc/apt/keyrings
sudo curl -fsSL https://download.docker.com/linux/ubuntu/gpg -o /etc/apt/keyrings/docker.asc
sudo chmod a+r /etc/apt/keyrings/docker.asc

# Add the repository to Apt sources:
echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.asc] https://download.docker.com/linux/ubuntu \
  $(. /etc/os-release && echo "${UBUNTU_CODENAME:-$VERSION_CODENAME}") stable" | \
  sudo tee /etc/apt/sources.list.d/docker.list > /dev/null
sudo apt-get update

At this step you should see an url from docker from the last command

Install Docker package :

sudo apt-get install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin

Allowing non-root users to run docker commands (from documentation) :

sudo groupadd docker
sudo usermod -aG docker $USER
newgrp docker

It's pretty usefull to get auto-completion on Docker CLI following the official documentation :

• Adding the right code snippet in the bashrc :


  cat <<EOT >> ~/.bashrc
  if [ -f /etc/bash_completion ]; then
      . /etc/bash_completion
  fi
  EOT


• Reloading the shell : source ~/.bashrc
• Creating folder to store bash completion scripts mkdir -p ~/.local/share/bash-completion/completions
• Generating the bash completion script for Docker docker completion bash > ~/.local/share/bash-completion/completions/docker

Click here if it worked

Docker swarm init

Let's initialize our Docker Swarm cluster :

docker swarm init

Once the swarm cluster is setup we can start deploying things with ``
